Replaceable Inserts

L225 Urethane Jaw Coupling Spider L225-SPIDER RING-URE

The L Type coupling consists of two standard L Type hubs and one spider. Urethane has greater torque capability than NBR (1.5 times), provides less dampening effect, and operates at a temperature range of -30° to 160° F (-34° to 71° C). Good resistance...

L225 Urethane Jaw Coupling Spider L225-SPIDER OCT-URE-1.8

The L Type coupling consists of two standard L Type hubs and one spider. Urethane has greater torque capability than NBR (1.5 times), provides less dampening effect, and operates at a temperature range of -30° to 160° F (-34° to 71° C). Good resistance...

L225 Nitrile Jaw Coupling Spider L225-SPIDER OCT-SOX-1-3/4

The L Type coupling consists of two standard L Type hubs and one spider. Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil resistant, resembles natural rubber in resilience and elasticity and operates effectively in...

L225 Hytrel Jaw Coupling Spider L225-SPIDER OCT-HYTREL-1-3/4

The L Type coupling consists of two standard L Type hubs and one spider. Hytrel is a flexible elastomer designed for high torque and high temperature operations. Hytrel can operate in temperatures of -60° to 250° F (-51° to 121° C) and has an excellent...

L225 Bronze Jaw Coupling Spider L225-SPIDER OCT-BRONZE-1.169

The L Type coupling consists of two standard L Type hubs and one spider. Bronze is a rigid, porous oil-impregnated metal insert exclusively for slow speed (maximum 250 RPM) applications requiring high torque capabilities. Bronze operations are not...

L190 Nitrile Jaw Coupling Spider L190-SPIDER-SOX

The L Type coupling consists of two standard L Type hubs and one spider. Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil resistant, resembles natural rubber in resilience and elasticity and operates effectively in...

L190 Hytrel Jaw Coupling Spider L190-SPIDER-HYTREL

The L Type coupling consists of two standard L Type hubs and one spider. Hytrel is a flexible elastomer designed for high torque and high temperature operations. Hytrel can operate in temperatures of -60° to 250° F (-51° to 121° C) and has an excellent...

L190 Urethane Jaw Coupling Spider L190-SPIDER OCT-URE-1-3/8

The L Type coupling consists of two standard L Type hubs and one spider. Urethane has greater torque capability than NBR (1.5 times), provides less dampening effect, and operates at a temperature range of -30° to 160° F (-34° to 71° C). Good resistance...

L190 Nitrile Jaw Coupling Spider L190-SPIDER OCT-SOX

The L Type coupling consists of two standard L Type hubs and one spider. Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil resistant, resembles natural rubber in resilience and elasticity and operates effectively in...

L190 Hytrel Jaw Coupling Spider L190-SPIDER OCT-HYTREL-1-3/8

The L Type coupling consists of two standard L Type hubs and one spider. Hytrel is a flexible elastomer designed for high torque and high temperature operations. Hytrel can operate in temperatures of -60° to 250° F (-51° to 121° C) and has an excellent...

L190 Bronze Jaw Coupling Spider L190-SPIDER OCT-BRONZE-1-3/8

The L Type coupling consists of two standard L Type hubs and one spider. Bronze is a rigid, porous oil-impregnated metal insert exclusively for slow speed (maximum 250 RPM) applications requiring high torque capabilities. Bronze operations are not...

L150 Nitrile Jaw Coupling Spider L150-SPIDER-SOX-10 PAK

The L Type coupling consists of two standard L Type hubs and one spider. Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil resistant, resembles natural rubber in resilience and elasticity and operates effectively in...
