Internal SAE Phosphated Inverted Retaining Ring HOI-0400-PA

Overview
Reviews

Product Description

Functions like an HO standard internal series ring in a housing/bore except the lugs are "reversed". This version reduces the distance the lugs project into the inner circumference of the housing/bore and allows for another assembly to pass through unimpeded

With regards to the HOI series retaining rings, only the black phosphate coated (HOI-PA) rings are listed in this database, however other finishes are available upon special request

Alternate Finishes Available:

(HOI-H) Stainless Steel - PH 15-7 Mo is an extra strength corrosion-resistant stainless steel, capable of preventing atmospheric oxidation at temperatures up to 900º F

(HOI-ZD) Yellow Zinc Dichromate - It affords the metal excellent salt spray protection (96 hours) and is particularly effective for applications exposed to seawater. This retaining rings zinc plated finish utilizes a mechanical plating process which effectively eliminates hydrogen embrittlement

(HOI-Z3X) Trivalent Chromate Zinc Plus Sealer

(HOI-ZF) Clear Bright Zinc

DMR Retaining Rings

Product Videos

Custom Field

Alternate manufacturers numbers Waldes Truarc 5008-400

Material finish Phosphate coating

Ring material Carbon spring steel (SAE 1060-1090/UNS G10600-G10900)

Size range .625 ~ 4.00"

Recommendation The standard finish is recommended over unfinished plain steel since it offers extended shelf-life protection against rusting
