External SAE Phosphated Tamper Proof Retaining Ring SHM-0037-PA

Overview
Reviews

Product Description

The SHM also functions like an SH retaining ring, but in "smaller" applications. It is also a tamper proof ring which does not have any lugs and can not be easily removed once installed

With regards to the less common SHM series retaining rings, only one size of the available 12 sizes is listed in this database and only in black phosphate. This is done so you are made aware that they are available for order should circumtances demand these types of retaining rings be installed in your machinery. As well, other finishes in this same series are available upon special request

Alternate Finishes Available:

(DC-H) Stainless Steel - PH 15-7 Mo is an extra strength corrosion-resistant stainless steel, capable of preventing atmospheric oxidation at temperatures up to 900º F

(SHM-ZD) Yellow Zinc Dichromate - It affords the metal excellent salt spray protection (96 hours) and is particularly effective for applications exposed to seawater. This retaining rings zinc plated finish utilizes a mechanical plating process which effectively eliminates hydrogen embrittlement

(SHM-Z3X) Trivalent Chromate Zinc Plus Sealer

(SHM-ZF) Clear Bright Zinc

DMR Retaining Rings

Product Videos

Custom Field

Material finish Phosphate coating

Ring material Carbon spring steel (SAE 1060-1090/UNS G10600-G10900)

RoHS & ELV compliant Yes

Size range .101 ~ .375"

Recommendation The standard finish is recommended over unfinished plain steel since it offers an extended shelf-life protection against rusting
