Product Description
With regards to the SH series retaining rings, only the black phosphate coated (SH-PA) and stainless steel (SH-H) rings are listed in this database, however other finishes are available upon special request
Alternate Finishes Available:
- (SH-ZD) Yellow Zinc Dichromate - It affords the metal excellent salt spray protection (96 hours) and is particularly effective for applications exposed to seawater. This retaining rings zinc plated finish utilizes a mechanical plating process which effectively eliminates hydrogen embrittlement
- (SH-Z3X) Trivalent Chromate Zinc Plus Sealer
- (SH-ZF) Clear Bright Zinc
DMR Retaining Rings
Product Videos
Custom Field
Alternate manufacturers numbers Waldes Truarc 5100-800
Material finish Phosphate coating
Ring material Carbon spring steel (SAE 1060-1090/UNS G10600-G10900)
Size range .1250 ~ 10.0"
Recommendation The standard finish is recommended over unfinished plain steel since it offers extended shelf-life protection against rusting
