  • External SAE Phosphated Standard Retaining Ring SH-0600-PA
  • External SAE Phosphated Standard Retaining Ring SH-0600-PA
  • External SAE Phosphated Standard Retaining Ring SH-0600-PA

    • External SAE Phosphated Standard Retaining Ring SH-0600-PA

    DMR

    $0.00
    (No reviews yet) Write a Review
    SKU:
    DAE SH-0600-PA
    Weight:
    0.22 LBS
    Alternate manufacturers numbers:
    Waldes Truarc 5100-600 / Dynaline 22975 (2/pk)
    Material finish:
    Phosphate coating
    Ring material:
    Carbon spring steel (SAE 1060-1090/UNS G10600-G10900)
    Size range:
    .1250 ~ 10.0"
    Recommendation:
    The standard finish is recommended over unfinished plain steel since it offers extended shelf-life protection against rusting

    Product Description

    With regards to the SH series retaining rings, only the black phosphate coated (SH-PA) and stainless steel (SH-H) rings are listed in this database, however other finishes are available upon special request

    Alternate Finishes Available:

  • (SH-ZD) Yellow Zinc Dichromate - It affords the metal excellent salt spray protection (96 hours) and is particularly effective for applications exposed to seawater. This retaining rings zinc plated finish utilizes a mechanical plating process which effectively eliminates hydrogen embrittlement
  • (SH-Z3X) Trivalent Chromate Zinc Plus Sealer
  • (SH-ZF) Clear Bright Zinc



     adobepdficon.png  DMR Retaining Rings



    •

    Product Videos

    Custom Field

    Alternate manufacturers numbers Waldes Truarc 5100-600 / Dynaline 22975 (2/pk)
    Material finish Phosphate coating
    Ring material Carbon spring steel (SAE 1060-1090/UNS G10600-G10900)
    Size range .1250 ~ 10.0"
    Recommendation The standard finish is recommended over unfinished plain steel since it offers extended shelf-life protection against rusting
