Chain Coupler Sprocket Half CB8020

Power-Link

$0.00

(No reviews yet) Write a Review

Chain couplers are one type among many coupler designs used to couple two drive shafts and allow for slight shaft misalignment.

Based on operating conditions, determine the service factor.

Obtain the desired horsepower by multiplying the horsepower transmitted by the service factor.

When the required shaft diameter exceeds the MAXIMUM bore diameter of the coupling you have chosen, use a coupling size that is one size larger.

Power-Link Catalog

Chain type 80-2R

Coupler bore 20mm (0.787")

Maximum machinable bore 90mm

Coupler cover CV8020

Coupler chain CH8020
