Product Description
These units have the same basic design as the RCJ series, except a concentric collar is used as the shaft-locking device instead of a self-locking cam collar
All RCJC units are equipped with GC-KRRB wide inner ring, concentric-collar bearings
The spherical outside diameter of the bearings is mounted in corresponding machined housing seats to provide the initial self-alignment
The bolt-hole spacing dimensions are interchangeable with the RCJ series and most competitive units
The units are factory-prelubricated, but a grease fitting is provided for relubrication if required
Concentric collars are supplied with all units
Safety end caps are available for selected sizes
Timken Fafnir Mounted Ball Bearing Catalog
Timken Fafnir Competitive Interchange Chart
Custom Field
Bearing Type Deep groove ball bearing
Shaft profile Round
Bearing material Hardened steel
Housing material Cast iron
Outer diameter profile Spherical
Locking device Concentric lock collar
