Product Description
600 SERIES STAINLESS STEEL CHAIN (AS)
The primary use of 600 AS series stainless steel chain is in corrosive and/or high-temperature environments which shorten the life of a standard carbon steel chain
The hardened round components provide up to a 50 percent higher working load and better wear life than 304 PS series stainless steel chain due to the higher carbon content
This chain is designed for drive applications that normally have a high number of articulationsCONNECTING LINKS
Standard connecting links are used when roller chain is operating under normal conditions
Spring-clip style connecting links are used for sizes 60H and smaller denoted by "S/C CO LINK"
Sizes 80 ~ 180H typically use a single special hardened "Sheppards" hook cotter pin denoted by "CT CO LINK SH"
Traditionl dual split cottered key connector links are also available in select chain sizes denoted by "SPL END CK"
Coated T-pins are used on chain sizes 200, 240 and 264 denoted by "CT CO LINK"
For severe applications, press fit connecting links are suggested denoted by "PF CO LINK"
Timken Drives General Catalog
Follow this link to access Timken's "Drives" customized roller chain attachment software.
Former "Drives" identification number
Former "Drives" identification number 71886
Chain classification ANSI C2060H
Chain strands 1
Quantity 1 link
Link type Spring clip connecting link
Material Type 600 stainless steel
