  • 6-7/16" Shaft Lovejoy® Series F-4.5 Exposed Bolt Rigid Flanged Gear Coupling Half F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW
  • 6-7/16" Shaft Lovejoy® Series F-4.5 Exposed Bolt Rigid Flanged Gear Coupling Half F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW
  • 6-7/16" Shaft Lovejoy® Series F-4.5 Exposed Bolt Rigid Flanged Gear Coupling Half F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW
  • 6-7/16" Shaft Lovejoy® Series F-4.5 Exposed Bolt Rigid Flanged Gear Coupling Half F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW
  • 6-7/16" Shaft Lovejoy® Series F-4.5 Exposed Bolt Rigid Flanged Gear Coupling Half F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW
  • 6-7/16" Shaft Lovejoy® Series F-4.5 Exposed Bolt Rigid Flanged Gear Coupling Half F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW
  • 6-7/16" Shaft Lovejoy® Series F-4.5 Exposed Bolt Rigid Flanged Gear Coupling Half F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW

    • 6-7/16" Shaft Lovejoy® Series F-4.5 Exposed Bolt Rigid Flanged Gear Coupling Half F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW

    Timken

    $0.00
    (No reviews yet) Write a Review
    SKU:
    TIM F-4.5E-HUB RGD-6-7/16-1-1/2X3/4KW
    UPC:
    UPC 69790490287
    Weight:
    0.00 LBS
    Series:
    F-4.5
    Shaft diameter:
    6-7/16"
    Keyway size:
    1-1/2 x 3/4"
    Coupling type:
    Gear coupler

    Product Description

  • F type rigid hubs, solid & rough stock bore - exposed and shrouded bolt designs
  • For use with FFR (flex-rigid) or FRR (rigid-rigid) couplings.
  • The FFR Type coupling consists of one flex hub, one rigid hub, one sleeve, and one accessory kit.
  • Exposed bolts (E) are the standard design for this coupling, though shrouded bolt (S) designs are available upon request through size 5.5.
  • The FFR Type has a max angular misalignment of 1.5 degrees (1.5 degrees per gear mesh).
  • The FRR Type coupling consists of two rigid hubs and one accessory kit.
  • Exposed bolts (E) are also the standard design for this coupling, though shrouded bolt (S) designs are available upon request through size 5.5.
  • The FRR Type coupling does not accommodate for any angular misalignment.
  • For larger torques, consider the FHD type gear coupling in sizes 10 through 30.

  • Timken’s Quick Flex® Elastomeric Coupling Configurator helps you quickly size Quick Flex coupling solutions for common applications.
  • By entering motor power (HP or kW), speed (rpm), and service factors, the configurator presents available Quick Flex coupling options, supporting faster selection and quoting.
  • Access the Quick Flex® Coupling Configurator to speed up your next coupling selection.

    adobepdficon.png Timken Lovejoy Master Catalog

    adobepdficon.png F & FA Flange Gear Coupling Installation Guide

    • Product Videos

    Custom Field

    Series F-4.5
    Shaft diameter 6-7/16"
    Keyway size 1-1/2 x 3/4"
    Coupling type Gear coupler
