  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078
  • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078

    • 2" Stroke 30 Metric Ton Hollow Centre Single Acting Cylinder 033078

    Strongarm

    $2,474.71
    (No reviews yet) Write a Review
    SKU:
    STG 033078
    UPC:
    UPC 059629998298
    Weight:
    23.10 LBS
    Model number:
    SACH302
    Product weight:
    23.1 lb.
    Cylinder effective area:
    7.39 in²
    Oil capacity:
    18.62 in³
    Retracted height (A):
    7.01"
    Extended height (B):
    9.53"
    Collar thread (C):
    4-1/2"-12
    Collar thread length (X):
    1.65"
    Outside diameter (D):
    4.53"
    Piston rod diameter (F):
    2.56"
    Base bolt circle diameter (U):
    3.63"
    Base hole thread (V):
    3/8"-16 UNC
    Base hole depth (Z):
    .55"
    Center hole diameter:
    1.31"
    Adding to cart… category.add_cart_announcement

    Product Description

  • Hollow plunger design allows for both push and pull forces
  • Complies with ASME B-30.1
  • High strength alloy steel for durability
  • Features collar threads, plunger threads and base mounting holes for optional fixture attachment
  • Heavy duty plunger return springs
  • High quality 3/8"-18NPT quick coupling
  • Grooved plunger end with threaded hole for mounting tilt saddles
  • Baked enamel finish for increased corrosion resistance

    The Surewerx group is parent too a collection of many prestigious and well known product lines sold across North America. Jet is only one product name under this umbrella of many brand names. Other product lines such as Strongarm, Sellstrom, and Startech Lighting are already available for online purchase on our webstore. Please note that there are more available product lines for sale by Surewerx that we have not yet created or made available online. To obtain information on these additional product lines, please access Surewerx's own website by clicking on the following hyperlink: Peakworks Rigging, Ranpro Footwear, Jackson Welding & Pioneer Safety. If something interests you, please feel free to email us for a personal quotation in the meantime.

    • Product Videos

    Custom Field

    Model number SACH302
    Product weight 23.1 lb.
    Cylinder effective area 7.39 in²
    Oil capacity 18.62 in³
    Retracted height (A) 7.01"
    Extended height (B) 9.53"
    Collar thread (C) 4-1/2"-12
    Collar thread length (X) 1.65"
    Outside diameter (D) 4.53"
    Piston rod diameter (F) 2.56"
    Base bolt circle diameter (U) 3.63"
    Base hole thread (V) 3/8"-16 UNC
    Base hole depth (Z) .55"
    Center hole diameter 1.31"
