  • 10" Stroke 25 Metric Ton Single Acting Cylinder 033039
  • 10" Stroke 25 Metric Ton Single Acting Cylinder 033039
  • 10" Stroke 25 Metric Ton Single Acting Cylinder 033039
  • 10" Stroke 25 Metric Ton Single Acting Cylinder 033039
  • 10" Stroke 25 Metric Ton Single Acting Cylinder 033039

    • 10" Stroke 25 Metric Ton Single Acting Cylinder 033039

    Strongarm

    $2,093.95
    (No reviews yet) Write a Review
    SKU:
    STG 033039
    UPC:
    UPC 059629998199
    Weight:
    31.00 LBS
    Model number:
    SACS2510
    Product weight:
    31 lb.
    Cylinder effective area:
    5.15 in²
    Oil capacity:
    52.86 in³
    Retracted height (A):
    14.72"
    Extended height (B):
    25"
    Collar thread (C):
    3-5/16"-12
    Collar thread length (X):
    2.13"
    Outside diameter (D):
    3.39"
    Piston rod diameter (F):
    2.24"
    Piston internal thread (O):
    1-1/2"-16 UN
    Piston thread length (P):
    1.02"
    Base bolt circle diameter (U):
    2.28"
    Base hole thread (V):
    1/2"-13 UNC
    Base hole depth (Z):
    .75"
    Adding to cart… category.add_cart_announcement

    Product Description

  • Complies with ANSI specifications
  • High strength alloy steel for safety and durability
  • Inside cylinder treated to enhance durability
  • Features collar threads, plunger threads and base mounting holes for optional fixture attachment
  • Heavy duty plunger spring return
  • High quality 3/8"-18 NPT quick coupling
  • Baked enamel finish for increased corrosion resistance

    The Surewerx group is parent too a collection of many prestigious and well known product lines sold across North America. Jet is only one product name under this umbrella of many brand names. Other product lines such as Strongarm, Sellstrom, and Startech Lighting are already available for online purchase on our webstore. Please note that there are more available product lines for sale by Surewerx that we have not yet created or made available online. To obtain information on these additional product lines, please access Surewerx's own website by clicking on the following hyperlink: Peakworks Rigging, Ranpro Footwear, Jackson Welding & Pioneer Safety. If something interests you, please feel free to email us for a personal quotation in the meantime.

    • Product Videos

    Custom Field

    Model number SACS2510
    Product weight 31 lb.
    Cylinder effective area 5.15 in²
    Oil capacity 52.86 in³
    Retracted height (A) 14.72"
    Extended height (B) 25"
    Collar thread (C) 3-5/16"-12
    Collar thread length (X) 2.13"
    Outside diameter (D) 3.39"
    Piston rod diameter (F) 2.24"
    Piston internal thread (O) 1-1/2"-16 UN
    Piston thread length (P) 1.02"
    Base bolt circle diameter (U) 2.28"
    Base hole thread (V) 1/2"-13 UNC
    Base hole depth (Z) .75"
